三種類型的圍擋施工做法了解
來源:http://mpmy.cn/ 發布時間:2022-04-18
圍擋施工現如今應用的范圍非常的廣泛,當然其中的要求也是要遵守,能夠更多的進行施工以及更好的保護好人員,那么下面來講三種類型的圍擋施工做法吧。
Enclosure construction is now used in a very wide range, of course, the requirements are also to comply with, can be more construction and better protection of personnel safety, then the following three types of enclosure construction practices.
園林綠化工程圍擋使用要求:
該圍擋用于7天以內的園林綠化工程。圍擋兩側支架端部設置不少于100公斤的砂袋做壓重。圍擋下腳用油漆噴刷成黃黑相間交通斑馬紋,斑馬紋高200mm、寬150mm、傾斜角45度,傾斜角指向車輛行駛方向。
Requirements for the use of enclosure in landscape engineering:
The enclosure is used for landscaping projects within 7 days. The end of the bracket on both sides of the enclosure should be equipped with sand bags of no less than 100 kg as the pressure. The lower foot of the fence is sprayed with paint into yellow and black traffic safety zebra grain, zebra grain 200mm high, 150mm wide, inclination Angle of 45 degrees, inclination Angle points to the direction of the vehicle.
應急搶險工程圍欄的要求:
應急搶險圍欄框架采用DN25的1寸鍍鋅管,圍欄采用1.2mm鍍鋅板制作。應急搶險圍欄采用插銷連接。應急搶險圍欄表面應粘貼反光膜。應急搶險圍欄上應注明搶險工程類型及建設單位名稱。
Requirements of emergency rescue engineering fence:
The frame of emergency rescue fence is made of DN25 1-inch galvanized pipe, and the fence is made of 1.2mm galvanized sheet. The emergency rescue fence is connected by bolt. Reflective film shall be pasted on the surface of emergency rescue fence. Type of emergency rescue project and name of construction unit shall be indicated on the emergency rescue fence.
交叉路口圍擋的要求:
距離交叉路口20m范圍內的機動車道的施工圍擋,圍擋距地面0.8m以上部分應當采用通透性圍擋,不得造成視覺、聽覺的盲區。圍擋下面安裝交通反光條,每6m在立柱上安裝警示燈。圍擋材料及下腳基座參照市政道路工程圍擋要求設置。
Requirements for intersection enclosure:
For the motor vehicle road construction enclosure within 20m distance from the intersection, transparent enclosure shall be used for the part above 0.8m distance from the ground, which shall not cause blind areas of vision and hearing. The traffic safety reflective strip is installed below the enclosure, and the warning light is installed on the column every 6m. Enclosure material and foot base shall be set according to the requirements of municipal road engineering enclosure.
臨街端頭及大門圍擋防護要求:
臨街端頭圍擋必須進行封阻,或設置大門。應設置交通標識、警示燈及防撞桶。圍擋材料參照市政道路工程圍擋要求設置,下腳用油漆噴刷成黃黑相間交通斑馬紋,斑馬紋高200mm、寬150mm、傾斜角45度,傾斜角指向車輛行駛方向。
Street end and gate enclosure protection requirements:
Street end enclosure must be blocked, or set a gate. Traffic safety signs, warning lights and anti-collision barrels should be set up. Enclosure material is set according to the requirements of municipal road engineering enclosure, and the lower foot is sprayed with paint into yellow and black traffic safety zebra pattern. The zebra pattern is 200mm high, 150mm wide, and the inclination Angle is 45 degrees. The inclination Angle points to the direction of the vehicle.
在此講解了三種類型的圍擋施工做法,除此之外,還有夾芯彩鋼板圍擋、PVC材料圍擋等圍擋的施工做法,詳細的要求您可以來我們網站mpmy.cn咨詢了解!
In this explained three types of enclosure construction practices, in addition, there are sandwich color steel plate enclosure, PVC material enclosure and other enclosure construction practices, detailed requirements you can come to our website mpmy.cn consultation understanding!
